GH-POF
Specifications
GH-POF Series Electro-Optical Characteristics:
| Code for parts GH-XXXXX |
Data Rate | Supply Voltage VCC |
Dissipation Current. Icc |
Pulse Width Distortion tw |
Propagation Delay Time | Package type |
|
|---|---|---|---|---|---|---|---|
| Mbps. NRZ | V | mA, max | ns | tᴘʟʜ(ns,max) | tᴘʜʟ(ns,max) | ||
| GH-TX3009-E13 | DC to 13.2 | 2.7~5.5 | 10 | ±25 | 100 | 100 | PL-4FE |
| GH-TX3007-E25 | 0.1 to 25 | 2.7~5.5 | 16 | ±12 | 60 | 60 | PL-4FE |
| GH-TX3007-E50 | DC to 50 | 2.7~5.5 | 10 | ±8 | 35 | 35 | PL-4FE |
| GH-TX3009-F13 | DC to 13.2 | 2.7~5.5 | 10 | ±25 | 100 | 100 | PL-4FF |
| GH-TX3007-F25 | 0.1 to 25 | 2.7~5.5 | 16 | ±12 | 60 | 60 | PL-4FF |
| GH-TX3007-F50 | DC to 50 | 2.7~5.5 | 10 | ±8 | 35 | 35 | PL-4FF |
| GH-TX3009-A13 | DC to 13.2 | 2.7~5.5 | 10 | ±25 | 100 | 100 | PL-4S |
| GH-TX3007-A25 | 0.1 to 25 | 2.7~5.5 | 16 | ±12 | 60 | 60 | PL-4S |
| GH-TX3007-A50 | DC to 50 | 2.7~5.5 | 10 | ±8 | 35 | 35 | PL-4S |
All information and data in this website are subject to change without prior notice.
