UVLED Applications in Germicidal Therapeutic Devices

Equipment for Oral Ulcers, Beauty Disinfection, and Rapid Wound Healing

This equipment is primarily used in treating oral ulcers, beauty disinfection, and skin wound healing. The device leverages the differential effects of various ultraviolet wavelengths on biological tissues, achieving functional expansion through multi-band UVLED chip packaging:

• 308nm band is suitable for treating skin conditions like vitiligo
• 240-280nm band provides sterilization and anti-inflammatory properties
• 405nm band combats superbugs

The device features an aluminum alloy housing with fiber optic transmission design, enhanced with 280nm packaging technology to improve sterilization capability. Its cold light source characteristics offer concentrated energy with minimal heat generation. Equipped with a 2200mAh lithium battery, it provides extended standby time, supporting over 500 short 10-second operations on a single charge. The product is mercury-free and environmentally friendly, highly portable, and low-maintenance, offering adjustable exposure time and automatic standby functions. It is suitable for ultraviolet sterilization treatment needs in medical institutions and beauty settings.

Technical Features

Different cells and microorganisms exhibit varying photobiological effects when exposed to ultraviolet light of different wavelengths:

• 308nm ultraviolet light is currently recognized as the optimal wavelength for treating skin conditions like vitiligo, psoriasis, and eczema
• UVC deep ultraviolet light can penetrate into bacteria, viruses, fungi, spores, and microorganisms, destroying DNA or RNA base pairs and affecting nucleic acid replication
• The 240-280nm band has special efficacy for wound healing and sterilization
• The 405nm band demonstrates strong killing power against superbugs like C.DIFF and MRSA

With the continuous development of UVLED technology, its applications in healthcare and beauty sectors have tremendous growth potential.

Product Advantages

1. Environmentally friendly: mercury-free with no harmful residues
2. Energy-efficient with long service life
3. Single-wavelength cold light source with minimal heat generation and concentrated energy, resulting in shorter treatment times and better effects
4. Battery-powered, compact, and convenient to use
5. Extremely low operational and maintenance costs

Technical Parameters

• Fiber optic transmission, can be disinfected
• Adjustable exposure time
• Configurable photosensitive time
• Automatic standby and shutdown
• Unique 280nm packaging technology providing powerful sterilization and wound healing capabilities
• Light power: 5mW
• Uses high-intensity 280nm LED for stronger sterilization capability
